SMART IRRIGATION AND FARM PROTECTION SYSTEM
Batch No: ___
1. Darshan<br>2. Vishnu Priya<br>3. Darshan K N<br>4. Darshan N<br>5. Chethan N
Problem Definition
Traditional irrigation wastes water due to manual control.
Crops may get damaged due to lack of timely watering.
Farms are vulnerable to animal or human intrusion.
Manual monitoring of fields is difficult and time-consuming.
There is a need for an automated irrigation and protection system.
Methodology
Soil moisture sensor measures soil water level.
Arduino microcontroller processes sensor data.
Relay module controls water pump automatically.
Servo motor rotates sensors for wider area coverage.
PIR sensor detects motion in the field.
Buzzer and LED alert when motion is detected.
System Block Diagram
Soil Moisture Sensor → Arduino → Relay → Water Pump
PIR Sensor → Arduino → Buzzer & LED
Arduino → Servo Motor (Sensor Rotation)
Power Supply → Arduino & Components
System Working Explanation
Soil moisture sensor sends data to Arduino.
Arduino turns ON the pump when soil is dry.
Pump turns OFF when sufficient moisture is detected.
PIR sensor detects movement in the farm area.
When motion is detected, buzzer and LED turn ON.
Servo motor rotates sensors for better field coverage.
Key Applications
Smart agriculture systems
Water conservation in farming
Crop protection from animals
Home garden automation
Greenhouse monitoring systems
TinkerCad Results
Circuit designed and simulated in TinkerCad.
Soil moisture sensor response verified.
Relay switching tested successfully.
Servo motor rotation observed.
PIR sensor detection confirmed.
Hardware Prototype
Arduino UNO based hardware setup.
Soil moisture sensor connected to soil.
Water pump controlled using relay.
PIR sensor mounted for motion detection.
Buzzer and LED connected for alerts.
Future Scope
Integration with IoT for mobile monitoring
Solar power supply for energy efficiency
SMS or app-based alerts
Weather-based irrigation control
Large-scale farm implementation
Conclusion
System automates irrigation efficiently.
Water usage is reduced significantly.
Crop safety is improved using motion detection.
Reduces manual effort and increases productivity.
Suitable for modern smart farming.
Thank You
