Vacuum Piston Valve Systems
High-Efficiency Discharge Solutions (ø63 mm & ø90 mm)
Standardized Certification
Our vacuum piston valves are engineered for reliability and safety. Both the ø63 mm and ø90 mm models are fully certified according to EN 16932-3 standards, ensuring compliance for residential and commercial infrastructure projects.
Core System Features
Fully submersible design (SS / EPDM / POM construction)
Zero maintenance required for operational longevity
Applicable for diverse discharge requirements
ø63 mm Piston Valve
The 63mm model is designed for efficiency, boasting a cycle duration of 10–15 seconds with a discharge capacity of up to 250 liters per cycle. Ideal for residential applications requiring consistent performance.
ø90 mm Piston Valve
The larger 90mm variant offers rapid discharge, completing cycles in just 6–8 seconds. With a massive capacity of up to 450 liters per cycle, it is tailored for commercial and high-discharge needs.
Discharge Capacity Comparison
Comparison of maximum liters per cycle between the two valve sizes.
Cycle Duration Efficiency
Lower duration indicates faster cycle completion speeds (values in seconds).
Full Technical Specifications Source
Applications & Maintenance
Available in ø63 mm and ø90 mm sizes to suit all needs.
Ideal for residential, commercial, and high-discharge applications.
Constructed for longevity: No maintenance required.
The ultimate solution for reliable, maintenance-free vacuum sewage transport.
